Defender 110 Specifications

1993 US/Canada Defender 110 Standard Vehicle Features:
Limited Edition number plaque (USA): XXX/500
Air Conditioning
Front brush bar
Rear bumper with integral step and Class III towing receiver
Full Carpeting
Lockable cubby box
AM/FM radio/cassette with four speakers
Auto-dimming rearview mirror
Side runners
Heated front windshield
Heated rear window
High mounted center brake light
Safari cage with integral luggage bars
Detachable roof rack with rear ladder
Seating Capacity: Nine (2 + 3 + [2 + 2] )
Color: Alpine White with grey hound's-tooth Moorland cloth interior
Optional power winch available

Mechanics:
14 gauge steel boxed "ladder" design frame
Aluminum body bolted directly to chassis frame.
3.9 Liter V8 Engine
3947 cc 8 cylinder
Cast aluminum alloy cylinder heads and block
Dry steel cylinder liners
Bore: 93.98mm (3.7in)
Stroke: 71.12mm (2.8in)
Compression ratio 9.35:1
Max. Power (SAE net) : 180 bhp @ 4750 rpmMax.
Torque: 227 ft-lb.) @ 3250 rpm

Gearbox: LT77S Five speed manual with synchromesh

Transfer box: LT230-T Permanent four-wheel drive, two-speed with manual locking center differential

Axles:
Front: Spiral bevel, enclosed constant-velocity joints, fully-floating hubs
Rear: Spiral bevel, fully floating hubs
Ratio: Front and Rear: 3.54:1
Towing Capacity:
Trailer (On or Off Road): 1650lb (750 kg)
Trailer with Brakes:
Off-Road: 2200lb (1000 kg)
On-Road low range: 7700lb (3500 kg)
On-Road high range: 5000lb (2275 kg)

Performance:
Approach Angle: 50 (degrees)
Departure Angle: 26 (degrees)
Wading Depth: 20 inches
Maximum gradient: 45 degrees (all vehicles)

Suspension:
Front: Coil springs, beam axle located by radius arms and Panhead Rod
Rear: Coil spring, beam axle located by trailing links
central 'A' frame with ride-leveling unit and anti-sway bar

Steering:
Power assisted worm and roller design, 4 turns lock to lock

Brakes:
Front: Discs with 4 piston calipers, 11.75in/299mm disc diameter
Front: Drums with wheel cylinder, 11in/280mm drum diameter

Fuel Tank:
20.4 US Gallons/77.2 Liters

Weights:
Estimated Curb Weight: 4848lbs/2200kg
Gross Vehicle Weight Rating (GVWR): 6504lbs/2950kg

Dimensions:
Overall length: 181.1in/4599mm
Overall height: 81.3in/2065mm - with rack: 90.0in/2286mm
Overall Width: 70.5in/1790mm
Wheelbase: 110.0 in/2794mm
Track front and rear: 58.5 in/1486mm
Ground clearance under differential: 8.5 in/215mm
